Gigabyte B650M D3HP AX

AM5, AMD B650, mATX
Price in EUR including VAT, free shipping
2Ratings
BrandMore from Gigabyte
Delivered Mon, 20/1
9 items in stock

Product details

Gigabyte B650M D3HP AX.

Key specifications

Processor family
Ryzen 5 7th Gen,
Ryzen 7 7th Gen,
Ryzen 9 7th Gen
Memory type
DDR5 RAM
Number of memory modules (RAM)
4 x
Internal connection options
M.2 (2x),
S-ATA III (4x)
Wireless transmission
Bluetooth,
Wi-Fi
Mainboard features
Clear CMOS Button,
Front panel audio connector,
Reset button,
Trusted Platform Module
Item number
40077901

General information

Manufacturer
Gigabyte Technology
Category
Motherboards
Manufacturer no.
B650M D3HP AX
Release date
6.9.2024

Motherboard properties

Form factor
Micro ATX (mATX)
Processor socket
AM5
Chipset
AMD B650
Mainboard features
Clear CMOS Button,
Front panel audio connector,
Reset button,
Trusted Platform Module
Operating system compatibility
Windows,
Windows 10
BIOS type
UEFI AMI
Wireless transmission
Bluetooth,
Wi-Fi
Wi-Fi standard
Wi-Fi 1 / 802.11b,
Wi-Fi 2 / 802.11a,
Wi-Fi 3 / 802.11g,
Wi-Fi 4 / 802.11n,
Wi-Fi 5 / 802.11ac,
Wi-Fi 6 / 802.11ax

Processor

Processor family
Ryzen 5 7th Gen,
Ryzen 7 7th Gen,
Ryzen 9 7th Gen

Memory

Memory form factor
DIMM
Number of memory modules (RAM)
4 x
Max. memory (RAM)
192 GB
Memory chip
DDR5 SDRAM
Max. RAM OC
7600 MHz
Supported memory speed
4800 MHz,
5200 MHz,
5600 MHz,
6000 MHz,
6200 MHz,
6400 MHz,
6600 MHz,
7000 MHz
Memory type
DDR5 RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
DisplayPort (2x),
HDMI (1x)
Video connection version
Display port 1.4,
HDMI 2.1

Network

Network connections
RJ45 (1x)
Ethernet controller brand
Realtek
Ethernet controller
Realtek RTL8125
Max. port speed
2.50 Gbit/s

Audio

Chip
Realtek ALC897
Audio channel
7.1 Channel
Audio Connections
Headphone output (1x),
Jack 3.5mm (3x),
Jack 3.5mm Microphone In (1x)

Data storage

RAID configuration
0,
1,
10

Internal interfaces

Internal connection options
M.2 (2x),
S-ATA III (4x)
Expansion slot
PCI Express x1 (1x),
PCI Express x16 (1x)
PCI express version (max.)
4
Number of fan connector
2

Further connections

USB ports
USB-A,
USB-C
Peripheral connections
PS/2 Combo,
USB 2.0 Type-A (2x),
USB 3.2 Gen 1 (3x),
USB Type-C (1x)

Power supply

Power connectors
24-pin ATX,
8-pin ATX 12V

Scope of delivery

Scope of delivery
Norton Internet Security,
Sata Cables

Product dimensions

Length
244 mm
Width
244 mm
Height
35 mm

Package dimensions

Length
27 cm
Width
28 cm
Height
7 cm
Weight
1.10 kg
